D-Drive
Operators for Non-Balanced Roller Shutters And Grilles
Grifco’s D-Drive range delivers a chain and direct drive solutions for non-balanced roller shutter doors to suit low cycle and high cycle applications. Robust and reliable, with multiple component options, the D-Drive is an intelligent workhorse with trusted performance.
- Robust Chain & Direct Drive configurations
- Single and variable speed options available for soft open / soft close
- Solutions up to 1,400 Nm
- Comprehensive logic onboard
- Relay Expansion Boards available
- Non-handed
- 2 year Grifco conditional warranty
- Rated for low and high duty cycle applications
- Made in Germany
D-Drive Product Selector
The Grifco D-Drive Product Selector is to assist the selection of door hardware and door automation components from the Grifco D-Drive range.
Connecting the motor power cable to single speed contactor controllers
IR safety beam and safety mechanical brake wiring to single speed contactor controllers
Mains power wiring to single speed contactor controllers
Adjusting speed settings for variable speed inverter controllers
Commissioning DDC22 single speed contractor controller and adjusting limits
Connecting the external safety brake for chain drive systems
Connecting the motor power cable to variable speed inverter controllers
Installing external trigger devices to wall controllers
Installing safety beams for variable speed inverter controller
Light curtain connection to wall controllers
Mains power wiring to variable speed inverter controllers
Navigating the controller menu
Safety bump edge connection to wall controllers
Connecting encoder and solenoid brake to variable speed inverter controllers
Adjusting limits on contactor and inverter controllers
Connecting encoder and solenoid brake to single speed contactor controllers
KS112 three position key switch connection to D-Drive wall controllers
